Netengine 8000 M1c 02354jem Fixed Interface(2*10ge+20*ge),2*dc Power Enterprise Router Cr8pm1cbasc8
5.0
Échantillons:
1 000,0 $/pièce | Min. commande : 1 pièce
Expédition:
Fret maritime de soutien
Lieu d'origine:
Chine
Paiements:
L/C, D/A, D/P, T/T, Western Union, MoneyGram, OA
Délai d'exécution:
1-10 (pièces): 3 (jours), 11-100 (pièces): 7 (jours), 101-500 (pièces): 15 (jours),> 500 (pièces): à négocier (jours)
Personnalisation:
Logo personnalisé (Min. Commande : 10 000 ensembles), emballage personnalisé (min. Commande : 10 000 ensembles), Personnalisation graphique (Min. Commande : 10000 ensembles)
Nom de marque:
comment
Numéro de modèle:
CR8PM1CBASC8
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Veuillez remplir le formulaire ci-dessous pour demander un devis ou demander plus d'informations sur nous. Veuillez être aussi détaillé que possible dans votre message et nous vous contacterons dès que possible avec une réponse. Nous sommes prêts à commencer à travailler sur votre nouveau projet, contactez-nous maintenant pour commencer.
Poids
7 kg
Utilisation
Autres
Lieu d'origine
Guangdong, Chine
Taper
Routeur d'entreprise
وصف المنتجات
HW NetEngine 8000 series routers provide an all-service, intelligent router platform designed for the cloud era. Using ultra-broadband pipes to construct simplified networks, and Segment Routing (SR) and Segment Routing over IPv6 (SRv6) protocols to establish intelligent connections, NetEngine 8000 combines with HW's next generation Network Cloud Engine (NCE) to implement full-lifecycle automation and proactive Operations and Maintenance (O&M). An intent-driven approach frees customers from unnecessary constraints, unleashing network potential. Available in a range of form factors and applicable to core, aggregation, and access networks, the award-winning NetEngine 8000 offers high performance and reliability, with low power consumption and full evolution capabilities. Applications include functioning as a core node for an enterprise Wide Area Network (WAN), as an access node on a large enterprise network, as a Data Center Interconnect (DCI) node, or as a campus or Internet Data Center (IDC) network egress.
تفاصيل الصور
مواصفة
غرض
|
مواصفة
|
Cabinet installation standards
|
ETSI (21-inch); IEC (19-inch); IMB (3U)
|
الأبعاد بدون التغليف (الارتفاع × العرض × العمق) [مم (بوصة)]
|
44.5 mm x 442 mm x 220 mm (1.75 in. × 17.4 بوصة x 8.66 in.)
|
Dimensions with packaging (H x W x D) [mm(in.)]
|
255 mm x 585 mm x 390 mm (10.04 in. x 23.03 in. x 15.35 in.)
|
Chassis height [U]
|
1 U
|
الوزن بدون التعبئة والتغليف [كجم (رطل)]
|
3.9 kg (8.60 lb)
|
Weight with packaging [kg(lb)]
|
6.1 kg (13.45 lb)
|
Typical power consumption (with configuration) [W]
|
89.21 W
|
Typical heat dissipation (with configuration) [BTU/hour]
|
289.43 BTU/hour
|
MTBF [year]
|
45.43 سنة
|
MTTR [hour]
|
2 ساعة
|
Availability
|
0.99999
|
CPU
|
8-core 1.5 GHz
|
SDRAM
|
4 GB
|
Flash memory
|
64 MB
|
Storage
|
8 GB
|
Power supply mode
|
AC
|
Rated input voltage [V]
|
200 V–240 V/100 V–127 V dual-live wire, supporting 240 V HVDC
|
Input voltage range [V]
|
100 V to 240 V
|
Maximum input current [A]
|
4 A
|
Maximum input cable size [mm²]
|
Standard C13 cable
|
Front-end circuit breaker/fuse [A]
|
<000000>ge;2A
|
Heat dissipation mode
|
Air cooling
|
Airflow direction
|
From left to right
|
Noise at normal temperature (acoustic power) [dB(A)]
|
55 dB(A)
|
Switching capacity
|
344 Gbit/s(Bidirectional). The maximum allowed error is 0.01%. To be specific, 99.99% of the line rate is guaranteed.
|
Redundant power supply
|
1+1
|
Redundant fans
|
If a single fan fails, the system can still work for a short period of time at an ambient temperature of 50°C (122°F).
|
درجة حرارة التشغيل على المدى الطويل [°C(°F)]
| –40°C to +65°C (–40°F to +149°F)
|
Restriction on the operating temperature variation rate [°C(°F)]
|
<000000>le; 30°C/hour (54°F/hour)
|
Storage temperature [°C(°F)]
| –40°C to +70°C (–40°F to +158 °F)
|
Long-term operating relative humidity [RH]
|
5% to 95% RH, non-condensing
|
Storage relative humidity [RH]
|
5% to 100% RH, non-condensing
|
Long-term operating altitude [m(ft.)]
|
<000000>le; 4000 m (13123.2 ft.) (For the altitude in the range of 1800 m to 4000 m [5905.44 ft. to 13123.2 ft.], the operating temperature
of the device must decrease by 1°C [1.8°F] for every 220 m [721.78 ft.].) |
Storage altitude [m(ft.)]
| < 5000 m (16404 ft.)
|
