S380-H8T3ST B2 Gigabit electrical 1 Gigabit Optical (WAN)+8 Gigabit electrical (LAN) fiber optic wifi router
5.0
Samples:
$1000.0/piece | Min. order : 1 piece
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-10(pieces):3(days),11-100(pieces):7(days),101-500(pieces):15(days),>500(pieces):To be negotiated(days)
Customization:
Customized logo (Min. Order: 10000 sets),Customized packaging (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets)
Brand Name:
hw
Model Number:
S380-H8T3ST
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Use
other
Place of Origin
Guangdong, China
Type
Enterprise Switch
Products Description
2 Gigabit electrical 1 Gigabit Optical (WAN)+8 Gigabit electrical (LAN) fiber optic wifi router S380-H8T3ST
Details Images
Specification
|
Chassis material
|
Metal
|
|
Height [mm]
|
43.6 mm
|
|
Depth [mm]
|
160.0 mm
|
|
Wide [mm]
|
442.0 mm
|
|
Chassis height [U]
|
1
|
|
Weight without packaging [kg(lb)]
|
1.6 (3.53)
|
|
Weight with packaging [kg(lb)]
|
2.1 (4.63)
|
|
Typical power consumption [W]
|
11.25
|
|
Maximum power consumption [W]
|
11.5
|
|
Heat dissipation mode
|
Natural heat dissipation
|
|
Typical heat dissipation [BTU/hour]
|
38.4
|
|
Maximum heat dissipation [BTU/hour]
|
39.2
|
|
Power supply mode
|
AC built-in
|
|
Input voltage range [V]
|
AC input: 90 V AC to 264 V AC; 45 Hz to 65 Hz
|
|
Rated input voltage [V]
|
AC input: 100–240 V AC; 50/60 Hz
|
|
Maximum input current [A]
|
0.8 A
|
|
Number of card slots
|
0
|
|
Number of power slots
|
0
|
|
Memory
|
DDR4: 1 GB
|
|
Flash memory
|
NAND Flash: 512 MB
|
|
Redundant power supply
|
Not supported
|
|
Types of fans
|
None
|
|
Noise at normal temperature (acoustic power) [dB(A)]
|
Noise-free (no fans), < 30
|
|
Noise at normal temperature (acoustic pressure) [dB(A)]
|
Noise-free (no fans), < 20
|
|
Airflow direction
|
-
|
|
Restriction on the operating temperature variation rate [°C(°F)]
|
When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the
altitude increases by 220 m (722 ft.). |
|
Long-term operating temperature [°C(°F)]
|
0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.)
|
|
Storage temperature [°C(°F)]
|
–40°C to +70°C (–40°F to +158°F)
|
|
Long-term operating relative humidity [RH]
|
5% RH to 95% RH (non-condensing)
|
|
Long-term operating altitude [m(ft.)]
|
0–5000 m (0–16404 ft.)
|
|
Storage altitude [m(ft.)]
|
0-5000 m (0-16404 ft.)
|
|
MTBF [year]
|
63.71
|
|
MTTR [hour]
|
2
|
|
Availability
|
> 0.99999
|
|
Maximum number of physical ports on the entire device
|
11
|
|
Maximum number of 100GE ports
|
0
|
|
Maximum number of 40GE ports
|
0
|
|
Maximum number of 25GE ports
|
0
|
|
Maximum number of 10GE ports
|
0
|
|
Maximum number of GE ports
|
11
|
|
Maximum number of FE ports
|
10
|
|
Downlink ports
|
8 x GE LAN
|
|
Uplink ports
|
2 x GE WAN, 1 x GE (SFP) WAN
|
|
USB
|
Not supported
|
|
Console port
|
Not supported
|
|
Eth Management port
|
LAN port
|
|
Service port surge protection [kV]
|
Common mode: ±4 kV
|
|
Power supply surge protection
|
Power adapter: ±6 kV in differential mode and ±6 kV in common mode
|
|
RPS input
|
Not supported
|
|
PoE
|
Not supported
|
