S5735S-H24S4X-MA 98011041 4 Gigabit Sfp,4 10-gigabit Sfp+ S5735s-h Series Enterprise-class Managed Sfp Switch
5.0
Samples:
$630/piece | Min. order : 1 piece
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-10(pieces):3(days),11-100(pieces):7(days),101-500(pieces):15(days),>500(pieces):To be negotiated(days)
Customization:
Customized packaging (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets),Customized logo (Min. Order: 10000 sets)
Brand Name:
hw
Model Number:
S5735S-H24S4X-MA
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Use
other
Place of Origin
Guangdong, China
Type
Enterprise Switch
Products Description
CloudEngine S5735-S is a series of standard gigabit access switches that provide 24–48 flexible all-GE downlink ports andmfour fixed 10 GE uplink ports. S5735-S switches are designed for scenarios such as enterprise campus network access and aggregation, as well as data center access. Built on next-generation, high-performance hardware and with the Huawei Versatile Routing Platform (VRP), CloudEngine S5735-S switches boast advanced features, such as enhanced Layer 3 functionality, simplified O&M, flexible Ethernet networking, and mature IPv6 capabilities.
Details Images
Specification
|
arameter
|
S5735s-H series Enterprise-class Managed SFP Switch S5735S-H24S4X-MA with superior quality
|
|
packet forwarding rate
|
108/126Mpps
|
|
exchange capacity
|
1.36Tbps/13.6Tbps
|
|
fixed port
|
24 gigabit SFP, 4 10 gigabit SFP+, with 1 AC power supply
|
|
MAC Features
|
Follow IEEE 802.1d standard
|
|
|
Support MAC address automatic learning and aging
|
|
|
Support static, dynamic, black hole MAC entries
|
|
|
Support source MAC address filtering
|
|
VLAN Features
|
Support 4K VLANs
|
|
|
Support Guest VLAN, Voice VLAN
|
|
|
Support GVRP protocol
|
|
|
Support MUX VLAN function
|
|
|
Support VLAN based on MAC/protocol/IP subnet/policy/port
|
|
|
Support 1:1 and N:1 VLAN Mapping function
|
|
IP routing
|
Static routing, RIPv1/2, RIPng, OSPF, OSPFv3, ECMP, ISIS, ISISv6, BGP, BGP4+
|
|
SVF minimalist operation and maintenance
|
Supports zero-configuration plug-and-play as SVF Client
|
|
|
Supports automatic loading of client packages and patches
|
|
|
Support one-click automatic delivery of services
|
|
|
Client supports independent operation
|
|
interoperability
|
VBST is based on VLAN Spanning Tree Protocol (interworking with PVST/PVST+/RPVST)
|
|
|
LNP link type negotiation protocol (similar function to DTP)
|
|
|
VCMP VLAN centralized management protocol (similar to VTP)
|
|
|
For detailed interconnection certification and reporting, please visit here.
|
|
IP routing
|
Static routing, RIP, RIPng protocol
|
|
SVF minimalist operation and maintenance
|
Supports zero-configuration plug-and-play as SVF Client
|
|
|
Supports automatic loading of client packages and patches
|
|
|
Support one-click automatic delivery of services
|
|
|
Client supports independent operation
|
|
interoperability
|
VBST is based on VLAN Spanning Tree Protocol (interworking with PVST/PVST+/RPVST)
|
|
|
LNP link type negotiation protocol (similar function to DTP)
|
|
|
VCMP VLAN centralized management protocol (similar to VTP)
|
|
|
For detailed interconnection certification and reporting, please visit here.
|
