USG6310S-WL-OVS 50050067 Usg6000 Series Firewall Equipment
ports,supports WLAN access, and uses an external power adapter to supply power. The USG6305-W does not support port expansion.
|
Item
|
Description
|
|
|
Part number
|
50050061
|
|
|
System specifications
|
||
|
CPU
|
Multi-core 1.0 GHz processor
|
|
|
Memory
|
DDR3 1 GB
|
|
|
Flash
|
32 MB
|
|
|
NAND Flash
|
512 MB
|
|
|
Micro SD card
|
Optional. Purchase one 64-GB micro SD card from Huawei as required.
|
|
|
Hard disk
|
Not supported
|
|
|
SPUB (the service engine)
|
Not supported
|
|
|
4G LTE data card
|
Supported
|
|
|
Dimensions and weight
|
||
|
Dimensions (Ha聽x Wb聽x D)
|
44 mm x 300 mm x 220 mm (1.73 in. x 11.81 in. x 8.66 in., 1 U)
|
|
|
Weight
|
1.60 kg
|
|
|
Power consumption and heat consumption
|
||
|
Typical power consumption
|
10.7 W
|
|
|
Maximum power consumption
|
12.5 W
|
|
|
Typical heat consumption
|
36.5 BTU/hour
|
|
|
Maximum heat consumption
|
42.7 BTU/hour
|
|
|
Power specifications
|
||
|
AC model
|
Supported (external AC power adapter)
|
|
|
Rated input voltage (AC)
|
100 V to 240 V, 50 Hz/60 Hz
|
|
|
Maximum input voltage (AC)
|
90 V to 264 V, 47 Hz to 63 Hz
|
|
|
Maximum input current/Maximum output power
|
0.8 A/24 W or 1.0 A/36 W
|
|
|
Heat dissipation
|
||
|
Fan module
|
Has no fan and uses natural cooling.
|
|
|
Port density
|
||
|
Console port
|
1 (RJ45)
|
|
|
USB 2.0 port
|
1
|
|
|
Service ports in standard configuration
|
4 10/100/1000M autosensing Ethernet electrical ports
|
|
|
2 WiFi antenna connectors
|
||
|
Micro SD card slot
|
1
|
|
|
Expansion slot
|
None
|
|
|
WiFi access specifications
|
||
|
Wireless standards
|
IEEE 802.11 a/b/g/n/ac
|
|
|
Wireless rate
|
300 Mbit/s
|
|
|
Frequency bands
|
2.412 GHz to 2.472 GHz
|
|
|
5.18 GHz to 5.825 GHz
|
||
|
Maximum transmit powerc
|
2.4 GHz: 15 dBm
|
|
|
5 GHz: 20 dBm
|
||
|
Environment specificationsd
|
||
|
System reliability
|
MTBF (year)
|
13.8
|
|
MTTR (hour)
|
1
|
|
|
Long-term operating ambient temperature
|
0掳C to 45掳C
|
|
|
Storage ambient temperature
|
-40掳C to 70掳C
|
|
|
Operating ambient relative humidity
|
5% RH to 95% RH, non-condensing
|
|
|
Storage ambient relative humidity
|
5% RH to 95% RH, non-condensing
|
|
|
Altitude
|
5,000 m
|
|
