CloudEngine S5736-S48S4X-D 98011607 10g Ethernet Switch 48*GE SFP Ports Network Switch
5.0
Samples:
$2620/piece | Min. order : 1 piece
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-10(pieces):3(days),11-100(pieces):7(days),101-500(pieces):15(days),>500(pieces):To be negotiated(days)
Customization:
Customized logo (Min. Order: 10000 sets),Customized packaging (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets)
Brand Name:
hw
Model Number:
CloudEngine S5736-S48S4X-D
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Use
other
Place of Origin
Guangdong, China
Type
Enterprise Switch
Product Description
CloudEngine S5736-S series new standard full gigabit Ethernet switch, providing 24 ports PoE/ non-poe, 48 ports PoE/ non-poe, four upstream 10GE ports, and one expansion card slot.
CloudEngine S5736-S series switches are based on the new generation of high-performance hardware and Hua wei's VRP Versatile Routi ng Platform (software platform). They have enhanced three-layer features, simple operation and maintenance, flexible Ethernet networking. Mature IPv6 features are widely used in various industries such as healthcare, retail, mining, and Internet.
Rich service functions
Powerful power supply capacity
Intelligent operation and maintenance of the whole network
Details Images
Specification
|
Item
|
Specification
|
|
Dimensions without packaging (H x W x D) [mm(in.)]
|
Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.)
|
|
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm
x 442.0 mm x 235.8 mm (1.72 in. x 17.4 in. x 9.3 in.) |
|
|
Dimensions with packaging (H x W x D) [mm(in.)]
|
90 mm × 555 mm × 345 mm (3.54 in. x 21.85 in. x 13.58 in.)
|
|
Chassis height [U]
|
1 U
|
|
Weight without packaging [kg(lb)]
|
3.2 kg (7.1 lb)
|
|
Weight with packaging [kg(lb)]
|
4.3 kg (9.48 lb)
|
|
Typical power consumption [W]
|
87 W
|
|
Typical heat dissipation [BTU/hour]
|
296.85 BTU/hour
|
|
Maximum power consumption [W]
|
108 W
|
|
Maximum heat dissipation [BTU/hour]
|
368.51 BTU/hour
|
|
MTBF [year]
|
41.97 year
|
|
MTTR [hour]
|
2 hour
|
|
Availability
|
>0.99999
|
|
Noise at normal temperature (acoustic power) [dB(A)]
|
56.8 dB(A)
|
|
Noise at normal temperature (acoustic pressure) [dB(A)]
|
44.8 dB(A)
|
|
Number of card slots
|
0
|
|
Number of power slots
|
0
|
|
Number of fans modules
|
3
|
|
Redundant power supply
|
Not supported
|
|
Long-term operating temperature [°C(°F)]
|
-5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)
|
|
Short-term operating temperature [°C(°F)]
|
-5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5906 ft.)
|
|
Restriction on the operating temperature variation rate [°C(°F)]
|
When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the
altitude increases by 220 m (722 ft.). |
|
The equipment can operate beyond the normal operating temperature range for a short-term period, but the following conditions must
be met: |
|
|
The equipment operates at a temperature of over 45°C (113°F) consecutively for at most 96 hours in one year.
|
|
|
The equipment operates at a temperature of over 45°C (113°F) for a total of no more than 360 hours in one year.
|
|
|
The equipment operates at a temperature of over 45°C (113°F) for no more in 15 times in one year.
|
|
|
The equipment may be damaged or experience unexpected exceptions if any of the preceding limits is exceeded.
|
|
|
The equipment cannot start when the temperature is lower than 0°C (32°F). The maximum distance of optical modules used in these
conditions cannot exceed 10 km. |
|
|
Storage temperature [°C(°F)]
|
-40°C to +70°C (-40°F to +158°F)
|
|
Long-term operating relative humidity [RH]
|
5% to 95%, noncondensing
|
|
Long-term operating altitude [m(ft.)]
|
0-5000 m (0-16404 ft.)
|
|
Storage altitude [m(ft.)]
|
0-5000 m (0-16404 ft.)
|
|
Power supply mode
|
DC built-in
|
|
Rated input voltage [V]
|
-48 V DC to -60 V DC
|
|
Input voltage range [V]
|
-38.4 V DC to -72 V DC
|
|
Maximum input current [A]
|
6.0 A
|
|
Memory
|
2 GB
|
|
Flash memory
|
1 GB in total. To view the available flash memory size, run the display version command.
|
|
Console port
|
RJ45
|
|
Eth Management port
|
RJ45
|
|
USB
|
Not supported
|
|
RTC
|
Supported
|
|
RPS input
|
Not supported
|
|
Service port surge protection [kV]
|
-
|
|
Power supply surge protection [kV]
|
±2 kV in differential mode, ±4 kV in common mode
|
|
Types of fans
|
Built-in
|
|
Heat dissipation mode
|
Heat dissipation with fan, intelligent fan speed adjustment
|
|
Airflow direction
|
Air intake from left and front, air exhaustion from right
|
|
PoE
|
Not supported
|
|
Certification
|
EMC certification
|
|
Safety certification
|
|
|
Manufacturing certification
|
