描述

Fixed-configuration Module,AC power,548.9mm*217.6mm*41.2mm,sheet metal

BOM

02310MKG

模型

CR5MPWRBX070

Dimensions (H x W x D)

AC power box: 41.2 mm x 217.6 mm x 548.9 mm (1.62 in. x 8.57 in. x 21.61 in.)

Power module: 40.8 mm x 105 mm x 281 mm (1.61 in. x 4.13 in. x 11.06 in.)

重量

AC power box: 3.8 kg (8.38 lb)

Power module: 1.8 kg (3.97 lb)

Rated voltage

200 V AC to 240 V AC

Voltage range

180 V AC to 264 V AC

Maximum current

16 A

Typical power consumption

AC power box: 1.0 W

AC power box: 128.8 W

Typical heat dissipation

AC power box: 3.2 BTU/hour

AC power box: 417.9 BTU/hour
