H 3 C Cr-19k-mpu-20b Main Processing Unit For Cr19000-16

Processor

x86, eight-core @ 2.6 GHz

BIOS flash

16 MB

APP flash

2 GB

NVRAM

1 MB

DRAM type and size

DDR4 VLP RDIMM, default/max: 32 GB/128 GB

Hard disk

240 GB

Dimensions (H × W × D)

40 × 433 × 512 mm (1.57 × 17.05 × 20.16 in)

Weight

7.2 kg (15.87 lb)

Typical power consumption

230 W

Hot swapping

Supported

Ports

·     1 × console port

·     1 × USB 2.0 port (Type A, host mode)

·     1 ×10/100/1000BASE-T management port

·     4 × 10GBASE-R-SFP+ ports

·     2 × 1PPS/ToD time synchronization ports

·     2 × SMB clock input ports

·     2 × SMB clock output ports

·     EXT ports:

¡     1 × 10/100/1000BASE-T BMC port

¡     ETH ports: 1 × 10/100/1000BASE-T port and 2 × 10GBASE-R-SFP+ ports

¡     1 × USB 2.0 port (Type A)

Interface transmission rate

·     Console port: 9600 (default) to 115200 bps

·     10/100/1000BASE-T management port: 10/100/1000 Mbps

·     10GBASE-R-SFP+port: 10 Gbps

·     10/100/1000BASE-T BMC port: 10/100/1000 Mbps

·     ETH ports:

¡     10/100/1000BASE-T port: 10/100/1000 Mbps

¡     10GBASE-R-SFP+ port: 10 Gbps

Reset button

1

Compatible devices

CR19000-20, CR19000-MC
