High Quality And Reliability A Md Epyc 7663 Processor Inspur Nf5280a6 2u Rack Server
5.0
Samples:
$6399.0/piece | Min. order : 1 piece
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-10(pieces):3(days),11-100(pieces):7(days),101-500(pieces):15(days),>500(pieces):To be negotiated(days)
Customization:
Customized logo (Min. Order: 10000 sets),Customized packaging (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets)
Brand Name:
Inspur
Model Number:
NF5280A6
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Memory(max)
32GB
Hard Drive
300gb
Form Factor
2U rack server
processor main frequency
2.45GHz
Power Supply
1300W*2
Processor Type
A MD EPYC 7663
Products Status
Stock
Private Mold
NO
Place of Origin
Beijing, China
Type
Rack
Inspur NF5280A6 Rack Server
Products Description
Inspur NF5280A6 is a high-end dual-socket server that uses the 3rd Gen A MD® EPYCTM Processors. NF5280A6 inherits the high quality and reliability of Inspur servers in different application scenarios. With the high computing performance, perfect ecologi- cal compatibility and configuration flexibility, NF5280A6 can fulfill a variety of complicated workloads, and particularly fits application scenarios such as data analysis and processing, cloud, and high-performance computing.
Powerful Performance
* Employing the 3rd Gen A MD® EPYCTM Milan Processors, NF5280A6 supports up to 64 cores and 128 threads per CPU, up to 280 W TDP, a maximum Turbo frequency of 3.7 GHz, and 256 MB L3 cache per CPU and XGMI2 interconnect links at 18 GT/s.
* Up to 32 DDR4 ECC memory modules (up to 3200 MT/s, RDIMMs and LRDIMMs), with the maximum capacity of 4 TB, are supported to deliver a high speed and superior availability.
* Employing the 3rd Gen A MD® EPYCTM Milan Processors, NF5280A6 supports up to 64 cores and 128 threads per CPU, up to 280 W TDP, a maximum Turbo frequency of 3.7 GHz, and 256 MB L3 cache per CPU and XGMI2 interconnect links at 18 GT/s.
* Up to 32 DDR4 ECC memory modules (up to 3200 MT/s, RDIMMs and LRDIMMs), with the maximum capacity of 4 TB, are supported to deliver a high speed and superior availability.
Flexible Expansion
* Support up to 16 × 3.5" drive or 28 × 2.5" drive.
* Support optional OCP NIC 3.0 module with multiple network port options (10/25/40/100/200 Gbps), delivering a more flexible network architecture to applications.
* Support up to 16 × 3.5" drive or 28 × 2.5" drive.
* Support optional OCP NIC 3.0 module with multiple network port options (10/25/40/100/200 Gbps), delivering a more flexible network architecture to applications.
* Support up to 8 standard PCIe expansion cards, further enhancing I/O performance.
* Support optional internal SATA/PCIe M.2 modules for diverse storage demands.
* Support optional internal SATA/PCIe M.2 modules for diverse storage demands.
Specification
|
Form Factor
|
2U rack server
|
|
Processor
|
One or two AMD® EPYCTM Milan series processors
|
|
Up to 64 cores (base frequency of 2.45 GHz)
|
|
|
Max. Turbo frequency at 3.7 GHz
|
|
|
256 MB L3 cache per CPU and XGMI2 interconnect links at 18 GT/s
|
|
|
TDP up to 280 W
|
|
|
Memory
|
Up to 32 DIMMs
|
|
8 memory channels per processor, and up to 2 memory slots per channel
|
|
|
Up to 3200 MT/s (1DPC)
|
|
|
RDIMMs and LRDIMMs supported
|
|
|
ECC, memory mirroring and memory rank sparing
|
|
|
Storage
|
Front drive: 24 x 2.5" hot-swap SATA/SAS/NVMe drive
|
|
12 x 2.5" or 3.5" hot-swap SATA/SAS/NVMe drive
|
|
|
Rear drive: 4 x 2.5" hot-swap SATA/SAS/NVMe SSD drive
|
|
|
4 x 3.5′′ (or 2.5") SATA/SAS/NVMe SSD drive (hot-swap)
|
|
|
Internal drive: 2 optional SATA M.2 drives or 1 PCle M.2 drive + 1 SATA M.2 drive
|
|
|
Storage Controller
|
Standard PCle RAID card controller and SAS card controller
|
|
Network Port
|
1 optional OCP NIC 3.0 module (10 Gbps, 25 Gbps, 40 Gbps, 100 Gbps, and 200 Gbps)
|
|
2 optional onboard 1-Gbps electrical ports
|
|
|
Standard PCIe form factor: 1 Gbps/10 Gbps/25 Gbps/40 Gbps/100 Gbps NIC
|
|
|
I/O Expansion Slot
|
Up to 8 PCIe slots Up to 2 double-width GPUs or 4 single-width GPUs 1 hot-swap OCP NIC 3.0 (x16)
|
|
Interface
|
2 rear USB 3.0 ports + 1 front USB 3.0 port + 1 front USB 2.0 port
|
|
1 front VGA port
|
|
|
1 rear VGA port
|
|
|
Fan
|
4 hot-swap fans with N+1 redundancy
|
|
PSU
|
550 W/800 W/1300 W/1600 W/2000 W CRPS standard PSUs with 1+1 redundancy
|
Detailed picture
