High Scalability A Md 7773x Cpu 2u 1-socket Rack Server Inspur Nf3280a6 Server
5.0
Samples:
$5000.0/piece | Min. order : 1 piece
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-10(pieces):3(days),11-100(pieces):7(days),101-500(pieces):15(days),>500(pieces):To be negotiated(days)
Customization:
Customized logo (Min. Order: 10000 sets),Customized packaging (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets)
Brand Name:
Inspur
Model Number:
NF3280A6
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Memory(max)
32GB
Hard Drive
300GB SAS 10K 2.5"
Form Factor
2U rack server
processor main frequency
2.2ghz
Power Supply
2*800W
Processor Type
a md EPYC 7773X
Products Status
Stock
Private Mold
NO
Place of Origin
Beijing, China
Type
Rack
Inspur NF3280A6 Rack Server
Products Description
High Scalability 2U 1-Socket Rack Server
Inspur NF3280A6 is a 2U1S rack server designed based on the 3rd GEN AMD® EPYCTM Milan Processors. With multiple cores, high base frequency and flexible expansion, NF3280A6 maximizes the performance of a single processor, making it comparable to the traditional dual-socket servers. It is designed for the needs of Internet, cloud computing, virtualization and big data and serves best in many scenarios such as Internet, high performance computing and cloud computing.
Powerful Performance
l NF3280A6 is built on the new generation AMD Milan Processors. The CPU supports up to 64 cores and 128 threads at the maximumTurbo frequency of 3.4 GHz and up to 280 W thermal design power (TDP). PCIe 4.0 ports support up to 128 lanes.
l NF3280A6 is built on the new generation AMD Milan Processors. The CPU supports up to 64 cores and 128 threads at the maximumTurbo frequency of 3.4 GHz and up to 280 W thermal design power (TDP). PCIe 4.0 ports support up to 128 lanes.
l 16 DDR4 ECC memory modules (RDIMM and LRDIMM) are supported with its data transfer rate up to 3200 MT/s under 1 DPC and 2933MT/s under 2 DPC.
The memory modules each have a maximum capacity of 128 GB, offering a total maximum capacity of 2 TB with high
speed and superior availability.
speed and superior availability.
l 8 NVDIMMs are supported to ensure memory data integrity in case of power failure without compromising on the memory capacity and bandwidth.
l An all-flash configuration of up to 24 hot-swap NVMe SSDs provides ten times the IOPS of high-end enterprise-level SATA
SSDs,with a 20% increase in storage capacity over the previous generation.
l An all-flash configuration of up to 24 hot-swap NVMe SSDs provides ten times the IOPS of high-end enterprise-level SATA
SSDs,with a 20% increase in storage capacity over the previous generation.
Specification
|
Form Factor
|
2U rack server
|
|
Processor
|
Supports 1 A MD® Milan® scalable processor:Up to 64 cores and 128 threads with a maximum Turbo frequency of 3.7 GHz
|
|
Memory
|
Up to 16 DIMMs Up to 3200 MT/s RDIMMs, LRDIMMs and NVDIMMs supported ECC, memory mirroring and memory hot spare
|
|
Storage
|
Front configuration:
12 x 3.5-inch SAS/SATA/NVMe drive 24 x 2.5-inch SAS/SATA/NVMe drive
|
|
Internal configuration:
Up to 2 x SATA M.2 or PCIe x4 M.2 drive 4 x 3.5-inch SAS/SATA drive
|
|
|
Rear configuration:
2 x 3.5-inch SAS/SATA drive
4 x 2.5-inch SAS/SATA/NVMe drive
|
|
|
Storage Controller
|
RAID controller and SAS controller 1 x onboard RAID Mezz card slot
|
|
Network
|
Optional OCP NIC 3.0 module with multiple network port options (1/10/25/40/100 Gbps)
|
|
I/O Expansion Slot
|
Up to 6 x standard PCIe 4.0 slot (2 x FHHL PCIe x16 slot + 4 x FHHL PCIe x8 slot or 3 x FHHL
|
|
PCIe x16 slot + 2 x FHHL PCIe x8 slot)
|
|
|
Ports
|
Front configuration: 1 x USB 3.0 port, 1 x USB 2.0 port and 1 x VGA port
|
|
Rear configuration: 2 x USB 3.0 port, 1 x VGA port and 1 x RJ45 port
|
|
|
Fans
|
4 hot-swap 8056 fans with N+1 redundancy
|
|
Power Supply
|
Output power of 800 W, 1300 W, 1600 W, 2000 W or above with 1+1 redundancy
|
