USG6530F-DPL1 Hisecengine Usg6000f Series Enterprise Rackmount Security Gateway Ai Multi-port Firewall
5.0
Samples:
$1000.0/piece | Min. order : 1 piece
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-10(pieces):3(days),11-100(pieces):7(days),101-500(pieces):15(days),>500(pieces):To be negotiated(days)
Customization:
Customized logo (Min. Order: 10000 sets),Customized packaging (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets)
Brand Name:
hw
Model Number:
USG6530F-DPL
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Simultaneous Sessions
/
Throughput
/
VPN Support
Yes
Products Status
Stock
Place of Origin
Guangdong, China
Type
Wired & Wireless
Products Description
HiSecEngine USG6500F series AI firewalls are new-generation AI firewalls launched for small enterprises, industry branches, and chain business organizations. With unique content detection engine (CDE), the USG6500F series can detect viruses with over 100 layers of compression and multi-layer hidden viruses. Through integrated deployment of the network and security controllers, network and security policies can be configured and delivered in a unified manner, reducing OPEX by 80%.
Details Images
Specification
|
Installation Type
|
Rack,Work bench,Against the wall
|
|
Cabinet installation standard
|
Cabinet with a depth of 300 mm or above
|
|
Chassis height [U]
|
1U
|
|
Wide [mm]
|
320 mm
|
|
Depth [mm]
|
220 mm
|
|
Height [mm]
|
43.6 mm
|
|
Weight without packaging [kg(lb)]
|
2.60 (5.73)
|
|
Weight with packaging [kg(lb)]
|
4.51 (9.94)
|
|
Maximum power consumption [W]
|
44.5
|
|
Maximum heat dissipation [BTU/hour]
|
151.83
|
|
Heat dissipation mode
|
Absorbing cold air into the device
|
|
Power supply mode
|
Built-in AC, external power adapter
|
|
Rated input voltage [V]
|
- Built-in AC: 100 V to 240 V, 50 Hz/60 Hz - External PoE adapter: 56 V DC
|
|
CPU
|
1 CPU, 4 cores/CPU, up to 1.4 GHz
|
|
Memory
|
DDR4 4 GB
|
|
NOR Flash
|
64MB
|
|
NAND Flash
|
2 GB
|
|
Hard disk
|
Optional. Purchase one 64-GB micro SD card from Huawei as required.
|
|
Number of power modules
|
1
|
|
Number of fan modules
|
1
|
|
Types of fans
|
Built-in
|
|
Storage temperature [°C(°F)]
|
0°C to 45°C
|
|
Long-term operating relative humidity [RH]
|
5% RH to 95% RH, non-condensing
|
|
Storage relative humidity [RH]
|
5% RH to 95% RH, non-condensing
|
|
Long-term operating altitude [m(ft.)]
|
0 m to 5000 m
|
|
Storage altitude [m(ft.)]
|
0 m to 5000 m
|
|
MTBF [year]
|
30.85
|
|
MTTR [hour]
|
1
|
|
Availability
|
0.999996
|
|
Console port
|
RJ45
|
|
Eth Management port
|
RJ45
|
