USG6715F Hisecengine Usg6000f Series Enterprise Rackmount Security Gateway Ai Multi-port Firewall
5.0
Samples:
$1000.0/piece | Min. order : 1 piece
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-10(pieces):3(days),11-100(pieces):7(days),101-500(pieces):15(days),>500(pieces):To be negotiated(days)
Customization:
Customized logo (Min. Order: 10000 sets),Customized packaging (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets)
Brand Name:
hw
Model Number:
USG6715F
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Weight
11 kg
Place of Origin
Guangdong, China
Products Description
HiSecEngine USG6500F series AI firewalls are new-generation AI firewalls launched by for small enterprises, industry branches, and chain business organizations. With unique content detection engine (CDE), the USG6500F series can detect viruses with over 100 layers of compression and multi-layer hidden viruses. Through integrated deployment of the network and security controllers, network and security policies can be configured and delivered in a unified manner, reducing OPEX by 80%.
Details Images
Specification
|
Item
|
Specification
|
|
Installation Type
|
Rack
|
|
Cabinet installation standard
|
USG6715F-AC (02354MKN): Cabinets with a depth of 800 mm or more
|
|
USG6715F-AC (02354MKN-001): Cabinets with a depth of 800 mm or more
|
|
|
USG6715F-DC (02354TQE): Cabinet with a depth of 800 mm or above
|
|
|
USG6715F-DC (02354TQE-001): Cabinet with a depth of 800 mm or above
|
|
|
Dimensions without packaging (H x W x D) [mm(in.)]
|
Typical dimensions (excluding the parts protruding from the body): 43.6 mm x 442 mm x 600 mm (1.72 in. x 17.40 in. x 23.62 in.)
|
|
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm
x 442 mm x 633 mm (1.72 in. x 17.40 in. x 24.92 in.) |
|
|
Dimensions with packaging (H x W x D) [mm(in.)]
|
260 mm x 590 mm x 790 mm
|
|
Chassis height [U]
|
1 U
|
|
Weight with packaging [kg(lb)]
|
15.48 kg (34.13 lb)
|
|
Weight without packaging [kg(lb)]
|
10.26 kg (22.62 lb)
|
|
CPU
|
USG6715F-AC (02354MKN): 2 CPUs, 16-core/CPU, 2.0 GHz dominant frequency
|
|
USG6715F-AC (02354MKN-001): 2 CPUs, 16-core/CPU, 2.0 GHz dominant frequency
|
|
|
USG6715F-DC (02354TQE): 2 CPUs, 16 cores/CPU, 2.0 GHz dominant frequency
|
|
|
USG6715F-DC (02354TQE-001): 2 CPUs, 16 cores/CPU, 2.0 GHz dominant frequency
|
|
|
Memory
|
USG6715F-AC (02354MKN): DDR4 DIMM 64GB TOTAL, 32GB/CPU, supporting ECC
|
|
USG6715F-AC (02354MKN-001): DDR4 DIMM 64GB TOTAL, 32GB/CPU, supporting ECC
|
|
|
USG6715F-DC (02354TQE): DDR4 DIMM, 64 GB TOTAL, 32 GB/CPU, ECC supported
|
|
|
USG6715F-DC (02354TQE-001): DDR4 DIMM, 64 GB TOTAL, 32 GB/CPU, ECC supported
|
|
|
Storage
|
32GB
|
|
NOR Flash
|
64 MB/CPU, 128 MB in total
|
|
Hard disk
|
USG6715F-AC (02354MKN): Optional. Purchase a 2.5-inch hot-swappable SATA hard disk (240 GB, 960 GB, 1000 GB or 1920 GB) from
Huawei. |
|
USG6715F-AC (02354MKN-001): Optional. Purchase a 2.5-inch hot-swappable SATA hard disk (240 GB, 960 GB, 1000 GB or 1920 GB) from
Huawei. |
|
|
USG6715F-DC (02354TQE): Optional. Purchase a hot-swappable 2.5-inch SATA hard disk (240 GB, 960 GB, 1000 GB or 1920 GB) from
Huawei on demand. |
|
|
USG6715F-DC (02354TQE-001): Optional. Purchase a hot-swappable 2.5-inch SATA hard disk (240 GB, 960 GB, 1000 GB or 1920 GB) from
Huawei on demand. |
|
|
Console port
|
RJ45
|
|
Eth Management port
|
RJ45
|
|
Maximum power consumption [W]
|
USG6715F-AC (02354MKN): 391 W
|
|
USG6715F-AC (02354MKN-001): 391 W
|
|
|
USG6715F-DC (02354TQE): 399 W
|
|
|
USG6715F-DC (02354TQE-001): 399 W
|
|
|
Maximum heat dissipation [BTU/hour]
|
USG6715F-AC (02354MKN): 1334.1 BTU/hour
|
|
USG6715F-AC (02354MKN-001): 1334.1 BTU/hour
|
|
|
USG6715F-DC (02354TQE): 1361.4 BTU/hour
|
|
|
USG6715F-DC (02354TQE-001): 1361.4 BTU/hour
|
|
|
MTBF [years]
|
35.14 years
|
|
MTTR [hours]
|
1 hours
|
|
Availability
|
0.999997
|
|
Power supply mode
|
USG6715F-AC (02354MKN): Built-in AC
|
|
USG6715F-AC (02354MKN-001): Built-in AC
|
|
|
USG6715F-DC (02354TQE): Built-in DC PM
|
|
|
USG6715F-DC (02354TQE-001): Built-in DC PM
|
|
|
Number of power modules
|
2
|
|
Rated input voltage [V]
|
USG6715F-AC (02354MKN):
|
|
AC: 100 V to 240 V, 50 Hz or 60 Hz
|
|
|
High-voltage DC: 240 V, DC
|
|
|
USG6715F-AC (02354MKN-001):
|
|
|
AC: 100 V to 240 V, 50 Hz or 60 Hz
|
|
|
High-voltage DC: 240 V, DC
|
|
|
USG6715F-DC (02354TQE):
|
|
|
+48 V DC
|
|
|
-48 V DC to -60 V DC
|
|
|
USG6715F-DC (02354TQE-001):
|
|
|
+48 V DC
|
|
|
-48 V DC to -60 V DC
|
|
|
Input voltage range [V]
|
USG6715F-AC (02354MKN):
|
|
AC: 90 V to 290 V, 45 Hz to 65 Hz
|
|
|
High-voltage DC: 190–290 V, DC
|
|
|
USG6715F-AC (02354MKN-001):
|
|
|
AC: 90 V to 290 V, 45 Hz to 65 Hz
|
|
|
High-voltage DC: 190–290 V, DC
|
|
|
USG6715F-DC (02354TQE):
|
|
|
+40 V DC to +57 V DC
|
|
|
-38.4 V DC to -72 V DC
|
|
|
USG6715F-DC (02354TQE-001):
|
|
|
+40 V DC to +57 V DC
|
|
|
-38.4 V DC to -72 V DC
|
|
|
Maximum input current [A]
|
USG6715F-AC (02354MKN): 8 A
|
|
USG6715F-AC (02354MKN-001): 8 A
|
|
|
USG6715F-DC (02354TQE): 38 A
|
|
|
USG6715F-DC (02354TQE-001): 38 A
|
|
|
Maximum output power [W]
|
USG6715F-AC (02354MKN): 600 W
|
|
USG6715F-AC (02354MKN-001): 600 W
|
|
|
USG6715F-DC (02354TQE): 1200 W
|
|
|
USG6715F-DC (02354TQE-001): 1200 W
|
Why Choose Us
1.Table And Wide Supply Chain System
We have established a perfect supply chain system to provide a wide range of products with reliable quality and reasonable price.
2.Competitive Price
We ensure the most competitive price.Warm reminders here, telecommunications equipment configuration is quite different, the price show
3.Safe And Easy Payment Solutions
We support a variety of payment methods, such as T/T, credit card, et
4.Strong Pre-Sales And After-Sales Services
To provide customers with professional pre- sales service, as well as after-sales technical Services
5.More Than 20 Years Industry Experience
We have been engaged in this industry more than 20 years, we have rich industry experience.
6.Fast Delivery And Shipping
Fast, professional and reliable delivery.
FAQ
Q: How about your main products?
A:Our product lines include Switches.Routers,OLTs,SDHs. Network Modules, Interface Cards, Security Firewalls, Wireless AP etc.
Q: What brand of products do you offer?
A:We are devoted to offering Huawei, ZTE, Cisco, Ruijie and other network equipment brands
Q:Can we get free samples?
A: Sorry, it is not available, but you can pay for one.
Q: What trade terms do you use ?
A: We offer EXW.FOB,CIF and CNF or as your request.
Q: How about your delivery time?
A:Generally, it will take 1 to 10 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.
Q: Do you test all your goods?
A:Yes we have professional engineer to test all devices before shipping.
