Usg9520 Hisecengine Usg9500 Series Enterprise Rackmount Security Gateway Ai Multi-port Firewall
5.0
Samples:
$1000.0/piece | Min. order : 1 piece
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-10(pieces):3(days),11-100(pieces):7(days),101-500(pieces):15(days),>500(pieces):To be negotiated(days)
Customization:
Customized logo (Min. Order: 10000 sets),Customized packaging (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets)
Brand Name:
hw
Model Number:
USG9520
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Simultaneous Sessions
without
Throughput
without
VPN Support
Yes
Products Status
Stock
Place of Origin
Guangdong, China
Type
Wired & Wireless
Products Description
Hua wei’s next-generation all-in-one DC firewall, the USG9500, delivers terabit-level performance to cloud service providers and large-scale enterprise campus networks.
It is typically deployed at the egress of cloud computing data centers, large enterprises, and campus networks to provide industry-leading protection capabilities. Boasting 99.999% reliability and integrating essential security features such as Network Address Translation (NAT), Virtual Private Network (VPN), Intrusion Protection System (IPS), virtualization, and Service Awareness (SA), the USG9500 reduces equipment room investment and Total Cost of Ownership (TCO) per Mbit/s, while enabling enterprises to construct cloud computing–oriented DCs with advanced security protection.
Details Images
Specification
|
Model
|
USG9520
|
USG9560
|
USG9580
|
|
Expansion Slots
|
3
|
8
|
16
|
|
Maximum Firewall Throughput
|
120 Gbit/s
|
960 Gbit/s
|
1.92 Tbit/s
|
|
Maximum Number of Concurrent Sessions
|
160,000,000
|
1,280,000,000
|
2,560,000,000
|
|
Basic Functions
|
Routing/Transparent/Composite mode, state validation detection, blacklist and whitelist, access control, Application Specific
Packet Filter (ASPF), security zone division, virtual firewall, smart route, and load balancing |
||
|
NAT/CGN
|
Destination NAT/PAT, NAT NO-PAT, source NAT-IP address persistence, source IP address pool grouping, NAT Server, bi-directional
NAT, NAT Application Layer Gateway (NAT-ALG), unlimited IP address expansion, policy-based destination NAT, port range pre-allocation, hair pinning mode, SMART NAT, NAT64, DS-Lite, and 6RD (IPv6 Rapid Deployment) |
||
|
NGFW Functions
|
Supports intrusion detection and prevention, URL filtering, antivirus, data loss prevention, etc.
|
||
|
PKI
|
PKI certificate requests (PKCS 10), Certificate Authority (CA)
|
||
|
PKI authentications: EAP-SIM, EAP-AKA
|
|||
|
PKI protocols: SCEP, OCSP, and CMPv2
|
|||
|
Self-signed certificate
|
|||
|
Virtual System
|
4,096-Virtual Firewall (VFW) definition, VLAN virtualization, security zones virtualization, user-defined virtual resources, route
between VFW, and VFW-based traffic CAR |
||
|
DDoS Mitigation
|
SYN-flood, ICMP-flood, TCP-flood, UDP-flood, and DNS-flood
|
||
|
Port-scan, Smurf, Tear-drop, and IP-Sweep
|
|||
|
IPv6-extension-header defense, TTL detection, TCP-mss detection, and attack log output
|
|||
|
Data Leak Prevention (DLP)
|
Identifies and filters the transferred files and contents. The USG9500 can identify more than 120 file types, regardless of
whether filename extensions are maliciously changed. In addition, the USG9500 can restore and implement content filtering for over 30 types of files, such as Word, Excel, PPT, PDF, and RAR files, to prevent leaks of critical enterprise information. |
||
