Hot Sale H 3c Uniserver R6900 G3 4u 4 Socket Rack Data Center Storage Networking Server
5.0
Samples:
$7000.0/piece | Min. order : 1 piece
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-10(pieces):3(days),11-100(pieces):7(days),101-500(pieces):15(days),>500(pieces):To be negotiated(days)
Customization:
Customized logo (Min. Order: 10000 sets),Customized packaging (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets)
Brand Name:
/
Model Number:
R6900 G3
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Hard Drive
600GB
Memory
32gb
Form Factor
4U Rack server
processor main frequency
2.3GHz
size
174.8x444x829.7mm
Power Supply
800W
Processor Type
Intel GOLD 5218
Products Status
Stock
Private Mold
NO
Place of Origin
Guangdong, China
Type
Rack
H3C UniServer R6900 G3 Server Series
Products Description
H3C latest UniServer R6900 G3 supports multiple computing nodes with modular design including 48 SFF hard disks or 16 NVMe SSD.R6900 G3 server delivers another level of reliability and availability, and is the best choice for mission critical business workload, virtualization, server consolidation and general 4-way data intensive application.
H3C UniServer R6900 G3 is based on the latest Xeon® Platinum and Gold Scalable Processors to improve server performance by 50% and 27% in the number of cores. Upgraded 2666MT/s DDR4 memory technology boosts speed by 11% over the DDR4 2400MT/s. 20 PCle 3.0 I/O channels achieves unprecedented expandability, with 94%/96% energy efficiency and 5-45℃ standard operating temperature ,it gives user highly energy efficiency.
H3C UniServer R6900 G3 is based on the latest Xeon® Platinum and Gold Scalable Processors to improve server performance by 50% and 27% in the number of cores. Upgraded 2666MT/s DDR4 memory technology boosts speed by 11% over the DDR4 2400MT/s. 20 PCle 3.0 I/O channels achieves unprecedented expandability, with 94%/96% energy efficiency and 5-45℃ standard operating temperature ,it gives user highly energy efficiency.
Specification
|
Computing
|
Up to 4 Xeon® Processor Scalable Platinum/Gold Family, 4/6/8/10/12/14/16/18/20/22/24/26/28 Cores, Maximum Support of 205W
|
|
Memory
|
Up to 48 DDR4 memory, Maximum support 2666MT/s, support RDIMM or LRDIMM, maximum capacity of 6TB
|
|
Storage Controller
|
Standard Array controller supports SATA RAID 0/1/10/5
Optional HBA card on Array card slot, support SATA/SAS RAID 0/1/10
Optional Array card on Array card-specific slot, support RAID 0/1/10/5/6/50/60/1E/Simple Volume
Optional standard PCIe 3.0 HBA and Smart Array card
|
|
FBWC
|
Support up to 2GB DDR3-1,866 MHz, 72-bit wide bus at 14.9 GB/s IO Performance
|
|
Local Storage
|
Supports SAS/SATA HDD/SSD; Maximum 48SFF front mounted drive
Supports a maximum of 16 NVMe, supports PCIe M.2 options
|
|
Network
|
Embedded 1Gbps HDM management network port; Optional 4×1GE electrical ports, 2×10GE Electrical Ports, 2×10GE optical ports
through mLOM, mLOM Supports NCSI function, optional standard PCIE 3.0 network adapter options
|
|
Expansion Slots
|
Upto 20 PCIe 3.0 slots (18 rear standard slots, 2 front, supports GPU)
|
|
Ports
|
Optional front VGA, standard rear VGA, serial port, 4 USB 3.0 (1 front, 2 rear, 1 built-in), 2 USB 2.0 (2 front)
|
|
GPU Support
|
Support 2 double wide GPU options upto 10.5”
|
|
CD-ROM
|
Supports external CD-ROM drive
|
|
Management
|
HDM agentless management tools (with independent management port) and H3C FIST management software
|
|
Power & Cooling
|
Optional Platinum Level 800W/1200W/1600W
Optional Platinum Level 800W 336VHDC
N+N redundant power supply
Passed 80 Plus certification, up to 96% energy efficiency conversion rate
Support hot-swappable redundant fans
|
|
Certification
|
Support CCC, CECP, SEPA Certification
|
|
Shape/ Chassis dimensions
|
4U
174.8mm(H)*444mm(W)* 807.4mm(D) (without safety panel)
|
