1.Multi service hybrid access small network: This is its core differentiation scenario. When there are both devices that require PoE power supply (such as wireless APs, IP cameras, IP phones) and devices that do not require power supply (such as desktop computers, printers, servers) in your network, its port configuration can be perfectly matched. You can reserve 8 PoE+ports for AP and camera, and 2 regular ports for computer or printer. One device can meet all access requirements without the need for additional non PoE switches or wasting PoE ports.

2.High cost-effective PoE power supply and 10 Gigabit uplink: Compared with the S5735-L8P4X-QA-V2 (8-port full PoE+10 Gigabit), this model offers a combination of 8 PoE+ports and 2 ordinary ports, but the total PoE power of the whole machine is also 125W. This means that if you only need to power 6-8 devices and have 2 non PoE devices to connect, choosing this model can not only meet your power supply needs, but also provide a wider range of port types, making it more cost-effective. Four 10G SFP+optical ports ensure ultra-high bandwidth for the uplink and forward all downlink data without blocking.

3.Integrated access to retail/dining/clinic locations: In a typical chain store, small clinic, or office, network equipment typically includes PoE cameras (monitoring), PoE APs (wireless coverage), PoE IP phones (voice), and cash registers/computers/printers (data). This switch can simultaneously meet the access and power supply needs of these four devices, achieving integrated carrying of network, voice, video, and monitoring, simplifying the network structure.

4.High security and intelligent operation and maintenance requirements environment: It supports comprehensive security controls, such as MAC/802.1x authentication, anti DOS attacks, etc., which can effectively prevent illegal access. At the same time, it supports technologies such as iStack, cloud management, and Telemetry for remote operation and fault location. Supports multiple three-layer routing protocols such as OSPF, and can be directly used as a core gateway in small networks

1. 10 Gigabit uplink: 4 × SFP+provides 10Gbps uplink bandwidth and supports 10 Gigabit fiber/high-speed copper cables

2. iStack Intelligent Stacking: Up to 9 devices can be virtually combined into one, and 10 Gigabit ports can be used as stacking links

3. Layer 3 routing: supports static RIP、OSPF、VRRP， Meet the three-layer forwarding needs of small and medium-sized networks

4. Reliability: STP/RSTP/MSTP, ERPS, SmartLink, fast link protection

5. Each port has 8 priority queues, supporting SP/DRR/hybrid scheduling

6. Dual speed tri color CAR, flow shaping, port speed limit

7. Based on L2-L4 laminar classification and 802.1p/DSCP priority mapping
