S5731-S24T4X 02353AHU S5700 Series 24* 10/100/1000base-T Ports Ethernet Switch 1

S5731-S24T4X 02353AHU S5700 Series 24* 10/100/1000base-T Ports Ethernet Switch 2

S5731-S24T4X 02353AHU S5700 Series 24* 10/100/1000base-T Ports Ethernet Switch 3

S5731-S24T4X 02353AHU S5700 Series 24* 10/100/1000base-T Ports Ethernet Switch 4

S5731-S24T4X 02353AHU S5700 Series 24* 10/100/1000base-T Ports Ethernet Switch 5

S5731-S24T4X 02353AHU S5700 Series 24* 10/100/1000base-T Ports Ethernet Switch 6

S5731-S24T4X 02353AHU S5700 Series 24* 10/100/1000base-T Ports Ethernet Switch 7

S5731-S24T4X 02353AHU S5700 Series 24* 10/100/1000base-T Ports Ethernet Switch

Samples:

$455.0/piece | Min. order : 1 piece

Shipping:

Support Sea freight

Place of Origin:

China

Payments:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA

Lead Time:

1-10(pieces):3(days),11-100(pieces):7(days),101-500(pieces):15(days),>500(pieces):To be negotiated(days)

Customization:

Customized logo (Min. Order: 10000 sets),Customized packaging (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets)

Brand Name:

Model Number:

S5731-S24T4X

Inquiry

Write a Review

Typical power consumption

88 W

Weight(with packaging)

8.4 kg (18.52 lb)

Memory (RAM)

4 GB

Storage temperature

-40°C to +70°C (-40°F to +158°F)

Maximum power consumption

114 W

Part Number

02353AHU

Use

other

Place of Origin

Guangdong, China

Type

Ethernet Switch

Products Description

The CloudEngine S5731-H series next-generation intelligent Gigabit Ethernet switch provides full Gigabit teleport access and a ten-gigabit uplink port, as well as an expansion card slot. CloudEngine S5731-H series switch is a new generation of intelligent Gigabit switch launched by . Based on its unified VRP (Versatile Routing Platform) software platform, with wired wireless deep integration capability, support board AC, up to 1 KAP; business Accompanying ability, provide consistent user experience; have VXLAN capability, support network virtualization function, meet the needs of the park network; at the same time, the series of switches built-in security probe, support abnormal traffic detection, encrypted traffic threat analysis, and the whole network threat trap function, is the best choice for large and medium-sized high-end-quality park network branches, small park network core and data center access.

Details Images

S5731-S24T4X 02353AHU S5700 Series 24* 10/100/1000base-T Ports Ethernet Switch 8

Specification

Item	Description
Memory (RAM)	2 GB
Flash	1 GB in total. To view the available flash memory size, run the display version command.
Mean time between failures (MTBF)	57.73 years
Mean time to repair (MTTR)	2 hours
Availability	> 0.99999
Service port surge protection	Common mode: ±6 kV
Power supply surge protection	Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode Using DC power modules: ±2 kV in differential mode, ±4 kV in common mode
Dimensions (H x W x D)	Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.4 in. x 16.5 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 43.6 mm x 442.0 mm x 448.0 mm (1.72 in. x 17.4 in. x 17.7 in.)
Weight (with packaging)	8.4 kg (18.52 lb)
Stack ports	10GE SFP+ ports on the front panel
RTC	Supported
RPS	Not supported
PoE	Not supported
Rated voltage range	AC input: 100 V AC to 240 V AC, 50/60 Hz High-Voltage DC input: 240 V DC DC input: -48 V DC to -60 V DC
Maximum voltage range	AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz High-Voltage DC input: 190 V DC to 290 V DC DC input: -38.4 V DC to -72 V DC
Maximum power consumption (100% throughput, full speed of fans)	114 W
Typical power consumption (30% of traffic load, tested according to ATIS standard)	88 W
Operating temperature	-5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.) NOTE: When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). The switch cannot be started when the ambient temperature is lower than 0°C (32°F).
Storage temperature	-40°C to +70°C (-40°F to +158°F)
Noise under normal temperature (27°C, sound power)	< 57.5 dB(A)
Relative humidity	5% to 95%, noncondensing
Operating altitude	0-5000 m (0-16404 ft.)
Certification	EMC certification Safety certification Manufacturing certification
Part number	02353AHU 02353AHU-001
