Item
|
Description
|
Memory (RAM)
|
1 GB
|
Flash
|
512 MB in total. To view the available flash memory size, run the display version command.
|
Mean time between failures (MTBF)
|
50.68 years
|
Mean time to repair (MTTR)
|
2 hours
|
Availability
|
> 0.99999
|
Service port surge protection
|
Common mode: ±7 kV
|
Power supply surge protection
|
±6 kV in differential mode, ±6 kV in common mode
|
Dimensions (H x W x D)
|
Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.7 in.)
|
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm
x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.) |
|
Weight (with packaging)
|
4.42 kg (9.75 lb)
|
Stack ports
|
Any 10/100/1000BASE-T ports or 1000BASE-X ports (applicable in V200R019C10 and later versions)
|
RTC
|
Not supported
|
RPS
|
Not supported
|
PoE
|
Not supported
|
Rated voltage range
|
AC input: 100 V AC to 240 V AC, 50/60 Hz
|
High-Voltage DC input: 240 V DC
|
|
Maximum voltage range
|
AC input: 90 V AC to 264 V AC, 47 Hz to 63 Hz
|
High-Voltage DC input: 190 V DC to 290 V DC
|
|
Maximum power consumption (100% throughput, full speed of fans)
|
Not providing the PoE function: 49 W
|
100% PoE loads: 441 W (PoE: 360
|
