Thinksystem Se350 1u Intel Xeon D-2123it Height Half Width Edge Server

Samples:

$3099.0/piece | Min. order : 1 piece

Shipping:

Support Sea freight

Place of Origin:

China

Payments:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA

Lead Time:

1-10(pieces):3(days),11-100(pieces):7(days),101-500(pieces):15(days),>500(pieces):To be negotiated(days)

Customization:

Customized logo (Min. Order: 10000 sets),Customized packaging (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets)

Brand Name:

JLS Future

Model Number:

SE350

Inquiry

Write a Review

Systems Management

Lenovo XClarity Administrator with mobile option

Hard Drive

2x 480GB A600i SATA

Memory

32GB

Form Factor

1U edge server

processor main frequency

2.2GHz

Power Supply

Dual-redundant external power supplies 100-240V AC

Processor Type

Intel Xeon D-2123IT

Products Status

Stock

Private Mold

Place of Origin

Guangdong, China

Type

Edge

ThinkSystem SE350 Edge Server

Products Description

The ThinkSystem SE350 is a purpose-built server that is half the width and significantly shorter than a traditional server, making it ideal for deployment in tight spaces. It can be mounted on a wall, stacked on a shelf or mounted in a rack. The ThinkSystem SE350 puts increased processing power, storage and network closer to where data is generated, allowing actions resulting from the analysis of that data to take place more quickly.

Unique performance and form
The ThinkSystem SE350 is an Xeon® D processor-based server, with a 1U height, half width and short depth case that can go anywhere. Mount it on a wall, stack it on a shelf or install it in a rack. This rugged Edge server can handle anything from 0-55°C as well as full performance in high dust and vibration environments.

Secure, connected, reliable
Information availability is another challenging issue for users at the Edge, who require insight into their operations at all
times to ensure they are making the right decisions. The ThinkSystem SE350 is designed to provide several connectivity options with wired and secure wireless Wi-Fi and LTE connection ability. This purpose-built compact server is reliable for a wide variety of Edge and IoT workloads.

Specification

Form Factor	1U height, half width edge server; Height: 40mm, Width: 215mm, Depth: 376mm
Processor	1-socket Xeon® D-2100, up to 16 cores
Memory	Up to 256GB in 4x slots, using 64GB DIMMs; 2133/2400/2666MHz TruDDR4
Internal Storage Options	2x M.2 2280 SATA boot drives + 8x M.2 22110 NVMe data storage drives 2x M.2 2280 SATA boot drives + 4x M.2 22110 NVMe/SATA data storage drives SED, high temperature, high capacity, and high endurance drive options Optional encryption key deletion on tamper or theft detection
RAID Support	Software RAID available Hardware RAID 0/1 for M.2 SATA Boot SSDs Hardware RAID 0/1 for M.2 SATA Storage SSDs
Mounting Options	Single node mounting options for desktop, VESA, DIN, wall, or ceiling Multi-node stackable bookend options E1 Enclosure for two nodes side-by-side and 4x power supplies. Depth: 735mm, Height: 1U E2 Short Depth Enclosure for two nodes sides by side + 4x power supplies: Depth: 440mm, Height: 2U Locking bezels and dust filter options
Power	Dual-redundant external power supplies 100-240V AC Single DC supply: -48VDC (-40VDC to -72VDC) @8.4A
Network Interfaces (Wired)	2x10GbE (SFP+), 2x 10/100MB/1GbE, 2x 1GbE management 2x10GbE (SFP+), 4x switch 10/100MB/1GbE, 1GbE management 2x10GbE, 2x 10/100MB/1GbE, 2x 1GbE management
Network Interfaces (Wireless)	Four wireless SMA connectors for LTE & Wi-Fi Wi-Fi 64/128-bits encrypted WEP, WPA, WPA2, 802.11 a/b/g/n/ac 3G/4G Cellular LTE 3GPP Release 12 450Mbps DL/50Mbps UL
Accelerators and PCIe Expansion	1x PCIe 3.0 x16 75W or 4x M.2 22110 Support for 1x T4 GPU for AI inference Support for GPU, FGPA, ASIC accelerators Support for operational technology networks 1x PCIe network card expansion 4x 1GbE RJ45 PCIe 2x 10GBASE-T PCIe 2x 10/25GbE SFP28 PCIe
I/O	Front: 1x VGA, 2x USB 3.0, 1x XClarity Controller management mini-USB Rear: 1x RJ45 Console Serial, 2x USB 2.0 USB and Console ports can be disabled
