WLAN Access Controllers AC6508 2*10GE SFP+ ports Outdoor Access Point
● Size:43.6 mm x 250 mm x 210 mm
● Port details: 10*GE ports, 2*10GE SFP+ ports, with the AC/DC adapter
● Place of Origin: Guangdong, China
● Forwarding performance: Maximum 120Gbps; supports both direct forwarding and tunnel forwarding modes
● Warranty: 1years
● MOQ: 1 pieces
Application scenarios
1. Wireless network core for large and medium-sized enterprise parks: This is its most core application scenario. In large office buildings, headquarters bases, and other scenarios, there are thousands of APs that need to be managed uniformly. The AC6805 can manage 10240 APs and, in conjunction with Huawei's full range of Wi Fi 6/7 APs, achieve wireless full coverage and seamless roaming in office areas, conference rooms, and public areas.
2. Wireless coverage of general education/higher education smart campus: In universities and large middle schools, wireless access is required for teaching buildings, libraries, dormitories, sports fields, etc. AC6805 can serve as the core of campus wireless networks, while also serving tens of thousands of teachers and students. In the case of Huawei Qiankun Cloud Platform, AC6805 was used to implement the cloud migration of campus network inventory.
3. Large scale medical/venue/hotel wireless network: In scenarios such as large hospitals, sports venues, conference centers, and star rated hotels that require high-density and high concurrency wireless coverage, AC6805 can centrally manage all APs and work with high-density APs to meet the simultaneous access needs of thousands of users. The wireless network construction project of Deyang People's Hospital adopts AC6805
Core functional characteristics
1. Air interface optimization and roaming: supports 802.11k/v/r intelligent roaming, SmartRadio RF optimization (DFA dynamic channel allocation, TPC transmission power control), load balancing and interference suppression; Compatible with multiple security certifications such as WPA3, 802.1X, MAC, Portal, Radius, etc
2. Networking and deployment: direct/side mounted deployment, cross L2/L3 network, NAT traversal (private network AP - public network AC); Built in simple Portal/AAA, reducing additional server investment
3. Operations and Reliability: Supports eSight, iMaster NCE Campus, Web UI, CLI; 1+1 AC hot standby/VRRP redundancy; One click fault diagnosis and visual monitoring
4. Protocol compatibility: Fully supports 802.11n/ac/ax/be and can smoothly transition to Wi Fi 6/7 networks
Detailed description
| Item | Specification |
|---|---|
| Installation Type |
|
| Dimensions without packaging (H x W x D) [mm(in.)] |
Basic: 43.6 mm x 250 mm x 210 mm (1.72 in. x 9.84 in. x 8.27 in.) Maximum: 43.6 mm x 250 mm x 215 mm (1.72 in. x 9.84 in. x 8.46 in.) |
| Weight without packaging [kg(lb)] | 1.9kg |
| Storage | Nand FLASH 1GB |
| Console port | RJ45 |
| Maximum power consumption [W] | 25.06 W |
| Maximum heat dissipation [BTU/hour] | 85.50 BTU/hour |
| Power supply mode | DC power adapter |
| Service port surge protection | 6 kV in common mode |
| Types of fans | None |
| Maximum number of physical ports on the entire device | 2 x 10GE (SFP+) + 10 x GE (RJ45) |
| Long-term operating temperature [°C(°F)] | 0°C to 45°C (32°F to 113°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum ambient temperature decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.) |
| Storage temperature [°C(°F)] | –40°C to +70°C (–40°F to +158°F) |
| Long-term operating relative humidity [RH] | 5% RH to 95% RH, non-condensing |
| Long-term operating altitude [m(ft.)] | –60 m to +5000 m (–196.85 ft to +16404.20 ft) |
| Atmospheric pressure [kPa] | 53kPa - 106kPa ETSI 300 019-2-3 |
| Ground | Ground |
| USB | 1 x USB 2.0 (host type A) port |
| MTBF [year] | 50 year |
| MTTR [hour] | 2 hour |
