Fast Shipping New AR201VW-P 02354975 Hua Wei Wi-Fi Router 1
Fast Shipping New AR201VW-P 02354975 Hua Wei Wi-Fi Router 1

Fast Shipping New AR201VW-P 02354975 Hua Wei Wi-Fi Router

    oops...!

    no product data.

    Go to homepage
    Weight
    3 kg
    Network
    Wireless Lan
    Use
    other
    Place of Origin
    Guangdong, China
    Type
    Enterprise Router
    Products Description



    next generation routers, the AR200 series are designed for enterprise branch offices and small businesses, delivering a comprehensive set of services, including routing, switching, voice, securi ty, and wireless access.
    Details Images
    Fast Shipping New AR201VW-P 02354975 Hua Wei Wi-Fi Router 2
    Fast Shipping New AR201VW-P 02354975 Hua Wei Wi-Fi Router 3
    Specification
    Item
    Specification
    System parameters
    Processor
    Dual-core, 533 MHz
    Memory
    512 MB
    Flash
    512 MB
    Micro SD card (default: sd1)
    None
    Hard disk
    Not supported
    Dimensions and weight
    Dimensions (H x W x D)
    With no mounting bracket installed: 44.0 mm x 300.0 mm x 216.4 mm (1.73 in. x 11.81 in. x 8.52 in.)
    With mounting brackets installed: 44.0 mm x 482.6 mm x 216.4 mm (1.73 in. x 19.00 in. x 8.52 in.)
    Weight
    2.8 kg
    Power specifications
    Rated input voltage range (AC)
    100 V to 240 V, 50 Hz/60 Hz
    Maximum input voltage range (AC)
    90 V AC to 264 V AC, 47 Hz to 63 Hz
    Maximum output current
    3 A
    Maximum output power
    36 W
    RPS power supply
    Not supported
    PoE power supply
    Not supported
    Power consumption
    Maximum power consumption
    16.1 W
    Heat dissipation
    Fan module
    None
    Airflow (facing the front panel)
    None
    Interface density
    Management interfaces
    1 (RJ45)
    CON/AUX interfaces
    1 (RJ45)
    USB 2.0 interfaces
    1
    Service interfaces (standard configuration)
    WAN interface: one ADSL-A/M interface
    LAN interfaces: eight FE electrical interfaces, in which LAN interface FE0 can be used as a WAN interface
    Extended slots
    Not supported
    Environment parameters
    Operating temperature
    0°C to 45°C (32°F to 113°F)

    NOTE:
    When the altitude is between 1800 m and 5000 m, the highest operating temperature reduces by 1°C every time the altitude increases
    by 220 m.

    Storage temperature
    -40°C to +70°C (-40°F to +158°F)
    Operating relative humidity
    5% to 95%, noncondensing
    Operating altitude
    < 5000 m (16404.2 ft.)
    Part number
    2353841
