Enterprise Routers AR6710-L26T2X4 With 50*GE RJ45, 2*10GE(SFP+), 1*USB 2.0, 4*SIC
● Model No.:AR6710-L26T2X4
● Size: 185 mm x 550 mm x 650 mm
● Manage ports:1×RJ45 Console、1×USB 2.0
● Place of Origin: Guangdong, China
● Core strengths:2 × 10GE SFP+, 2 × GE electrical WAN, 24 × GE electrical LAN, 4 × SIC expansion, dual power redundancy, ARM multi-core, strong IPSec/SD-WAN, 1U compact, routing and switching security integration.
● Warranty: 1years
● MOQ: 1 pieces
Application scenarios
1. Export gateway for small businesses/subsidiaries/stores: This is its most core application scenario. In small business headquarters, branches, or retail stores with 50-100 employees, it can serve as a network egress router, connecting 2 GE links and 1 10GE link (via 2 GE Combo WAN ports and 1 10GE optical port). Its 2 Gbps NAT forwarding performance can support daily internet, email, cash register system and other traffic for all employees. Huawei's official information clearly positions it as an ideal choice for "headquarters or branches of small and medium-sized enterprises".
2. Edge nodes for SD-WAN networking: With built-in SD-WAN functionality, they can serve as branch nodes (Spokes) for enterprise SD-WAN networks, enabling intelligent connections with headquarters or other branches. Supports typical SD-WAN performance of 1.2 Gbps, supports intelligent routing based on application and link quality, and ensures that critical applications (such as ERP and video conferencing) are always transmitted on the optimal link.
3. Multi service integration access node: integrates routing, switching VPN、 Integrating multiple functions such as security and voice. It can expand 5G/LTE, E1/T1, voice, firewall and other business cards through 2 SIC slots to meet the diversified development needs of enterprises in the future.
4. IPsec VPN gateway: Provides 1.6 Gbps IPsec performance, can establish encrypted tunnels through hardware acceleration, connect remote branches or employees on business trips, and ensure data transmission security.
5. Built in Wireless Controller (WAC): Supports built-in wireless controller function, default free management of 32 APs (expandable up to 128), can be used with Huawei AirEngine series APs to achieve wired and wireless integrated deployment, without the need to purchase additional hardware AC.
Core functional characteristics
- 1. Routing and Switching
- Supports IPv4/IPv6 dual stack, static routing RIP、OSPF、BGP、IS‑IS
- Support MPLS, L3VPN, VPLS, EVPN, QinQ, VLAN, port aggregation, and stacking
- Support NAT, PAT, port mapping, traffic control (QoS), ACL access control
- 2. VPN and Security
- Supports various VPNs such as IPSec, GRE, L2TP, SSL VPN, EVPN, etc
- Built in state firewall, URL filtering, Intrusion Prevention (IPS), AAA authentication, URPF attack prevention
- Support SSH, SNPv3, NETCONF/YANG encryption management
- 3. SD-WAN and cloud access
- Fully supports Huawei SD-WAN, including ZTP zero configuration, intelligent routing, application recognition, SLA guarantee
- Compatible with Huawei Cloud, AWS, Azure and other cloud platforms, supporting cloud edge collaboration
- Support 5G/4G wireless backup, multi WAN load balancing, and intelligent link scheduling
- 4. High reliability and operation and maintenance
- Supports high reliability features such as dual power redundancy, VRRP, BFD, FRR, NSR, GR, etc
- Support ZTP, USB opening, iMaster NCE centralized control
- Support multiple operation and maintenance methods such as Web, CLI, SNMP, NETCONF, Telemetry, etc
Detailed description
| Item | Specification |
|---|---|
| Installation type | Rack |
| Chassis height [U] | 1 U |
| Dimensions without packaging (H x W x D) [mm(in.)] |
|
| Dimensions with packaging (H x W x D) [mm(in.)] | 185 mm x 550 mm x 650 mm (7.28 in. x 21.65 in. x 25.59 in.) |
| Weight with packaging [kg(lb)] | 8.82 kg (19.44 lb) |
| Weight without packaging [kg(lb)] | 5.62 kg (12.39 lb) |
| CPU | Quad-core, 1.4 GHz |
| Memory | 4 GB |
| NAND Flash | 2 GB |
| Console port | RJ45 |
| RTC | Supported |
| LAN ports | 24 x GE electrical |
| WAN ports | 2 x 10GE SFP+, 2 x GE electrical |
| Number of service board slots | 4 |
| MIC slots (default/maximum) | 0/0 |
| SIC slots (default/maximum) | 4/4 |
| WSIC slots (default/maximum) | 0/2 |
| XSIC slots (default/maximum) | 0/1 |
| Redundant MPUs | Not supported |
| RPS input | Not supported |
| PoE | Not supported |
| IP rating | IP20 |
| MTBF [years] | 52.58 years |
| MTTR [hours] | 2 hours |
| Availability | 0.9999956580 |
| Typical power consumption [W] | 68 W |
| Maximum power consumption [W] | 98 W |
| Power supply mode |
|
| Number of power modules | 2 |
| Rated input voltage [V] |
Rated AC input voltage: 100 V to 240 V, 50 Hz or 60 Hz Rated DC input voltage: –48 V DC to –60 V DC |
| Input voltage range [V] |
Maximum AC input voltage: 90 V to 264 V, 47 Hz to 63 Hz Maximum DC input voltage: –38.4 V DC to –72 V DC |
| Maximum input current [A] |
AC: 3 A DC: 2.5 A |
| Maximum output power [W] |
AC: 350 W DC: 240 W |
| Redundant power supply | Dual power supplies in 1:1 backup mode |
| Types of fans | Built-in |
| Number of fan modules | 5 |
| Heat dissipation mode | Air cooling |
| Airflow | Left-to-right airflow |
| Noise at normal temperature (acoustic power) [dB(A)] | 57.2 dB(A) |
| Long-term operating temperature [°C(°F)] |
0°C to 45°C (32°F to 113°F) NOTE:
When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). |
| Long-term operating relative humidity [RH] | 5% RH to 95% RH, non-condensing |
| Long-term operating altitude [m(ft.)] | < 5000 m (16404.2 ft.) |
| Storage temperature [°C(°F)] | -40°C to +70°C (-40°F to +158°F) |
| Overtemperature alarm | Supported |
