Ethernet Switch S6730E-H6FX4Y2CZ-V2 Network Switch with 6*CFP2 hyper-converged ports
1U high-density multi speed campus aggregation switch, featuring 6 × 40GE+4 × 25GE+2 × 100GE optical port combination, suitable for medium and large campus aggregation, Wi Fi 7 AP high-density uplink, industry branch backbone interconnection, balancing high bandwidth and flexible networking
product Information
● Model No.: S6730E-H6FX4Y2CZ-V2
● Size: 442*420*43.6mm
● Port details: 6 × 40GE QSFP++4 × 1/2.5/10/25GE SFP28+2 × 40/100GE QSFP28, full optical port design
● Main features: All optical high-density multi rate port, high performance and low power consumption, flexible network expansion
● Application scenarios: Convergence of large and medium-sized parks, high-density uplink of Wi Fi 7 AP, backbone interconnection of industry branches, and multi rate optical port networking scenarios
● Warranty: 1 years
● MOQ: 1 pieces
Introduction
All optical high-density multi rate port: 6 × 40GE+4 × 25GE+2 × 100GE all-optical port combination, covering 40GE/25GE/100GE multi rate interconnection, adapting to different bandwidth access/uplink requirements, without electrical interface interference, suitable for pure optical networking scenarios.
Cloud network integration lightweight bearing: native support VXLAN+EVPN, distributed/centralized gateway flexible deployment, meet the campus network virtualization, multi service integration bearing needs, adapt to cloud networking upgrade.
High reliability and easy operation and maintenance: 1+1 redundant power supply+hot swappable fan, support ERPS loop protection, BGP fast convergence, with Telemetry real-time monitoring, iPCA network quality analysis, fault second level positioning, reduce operation and maintenance costs.
High performance and low power consumption: 1.44Tbps non blocking switching, taking into account high bandwidth forwarding and energy saving design, all optical ports reduce power consumption, adapt to the energy saving requirements of the computer room, and support MACsec end-to-end encryption to ensure data transmission security
.
Flexible expansion networking: uplink 100GE/40GE compatible, downlink 25GE/10GE adaptive, support horizontal expansion of equipment stack, meet the elastic growth of campus bandwidth, and protect early investment.
Parameters
| Project | Parameter details |
| Form | 1U rack type, 1+1 redundant power supply (AC/DC optional), hot swappable fan, 1 expansion slot |
| Port configuration | 6 × CFP2 PEN central port (single port supports 16 × 2.5/10GE SFP+channel, 96 accesses in total)+4 × 25GE SFP28+2 × 40/100GE QSFP28, all optical port design |
| Performance | The switching capacity is 4.8Tbps, the forwarding capacity is 9600Mpps, and it supports ≥ 96 access devices to meet the requirements of high-density terminal access |
| Core Features | Medical education enhancement (ERPS/STP loop protection visualization), VXLAN+EVPN，MACsec，iPCA，Telemetry， Support L2/L3VPN, HQoS, and adapt to PEN passive Ethernet all-optical scheme |
| Reliability | 1+1 power redundancy, stacking, VRRP/BFD, LACP link aggregation, to ensure the continuity of HIS/educational administration system and other key businesses |
| Typical scenario | Educational and medical park convergence/core, PEN passive Ethernet all-optical network center node, Wi Fi 7 AP high density uplink, IoT integration bearing |
