Samples:

$1088/piece | Min. order : 1 piece

Shipping:

Support Sea freight

Place of Origin:

China

Payments:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA

Lead Time:

1-1(pieces):3(days),2-10(pieces):7(days),11-100(pieces):15(days),>100(pieces):To be negotiated(days)

Brand Name:

Model Number:

S5735-L48PN4XE-A-V2

Inquiry

Write a Review

Weight

9 kg

Use

other

Place of Origin

Guangdong, China

Type

Enterprise Switch

Products Description

The S5700 series Ethernet switches are next-generation energy-saving switches developed by HW to meet the demand for
high-bandwidth access and Ethernet multi-service aggregation. Based on cutting-edge hardware and HW Versatile Routing Platform (VRP) software, the S5700 provides a large switching capacity, high reliability (double power slots and hardware Ethernet OAM), and high-density GE ports to accommodate 10 Gbit/s upstream transmissions. It also supports Energy Efficient Ethernet (EEE) and iStack. The S5700 can be used in various enterprise network scenarios. For example, it can function as an access or aggregation switch on a campus network, a gigabit access switch in an Internet data center (IDC), or a desktop switch to provide 1000 Mbit/s access for terminals.

Details Images

S5735-L48PN4XE-A-V2 98012370 24*10/100/1000/2.5gbase-t Ports(poe+),4*10ge Sfp+ Ports Port Poe Switch 7

S5735-L48PN4XE-A-V2 98012370 24*10/100/1000/2.5gbase-t Ports(poe+),4*10ge Sfp+ Ports Port Poe Switch 8

Specification


Item	Specification
Dimensions without packaging (H x W x D) [mm(in.)]	Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.40 in. x 16.54 in.)
Dimensions without packaging (H x W x D) [mm(in.)]	Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 446.0 mm (1.72 in. x 17.40 in. x 17.56 in.)
Dimensions with packaging (H x W x D) [mm(in.)]	185.0 mm x 650.0 mm x 550.0 mm (7.28 in. x 25.59 in. x 21.65 in.)
Chassis height [U]	1 U
Chassis material	Metal
Weight without packaging [kg(lb)]	6.51 kg (14.35 lb)
Weight with packaging [kg(lb)]	8.29 kg (18.28 lb)
Typical power consumption [W]	82.19 W
Typical heat dissipation [BTU/hour]	280.44 BTU/hour
Maximum power consumption [W]	Without PoE: 110.81 W
Maximum power consumption [W]	Full PoE load: 978.5 W (PoE: 828 W)
Maximum heat dissipation [BTU/hour]	Without PoE: 378.10
Maximum heat dissipation [BTU/hour]	Full PoE load: 3338.74
Static power consumption [W]	55.57 W
MTBF [years]	32.22 years
MTTR [hours]	2 hours
Availability	> 0.99999
Noise at normal temperature (acoustic power) [dB(A)]	67 dB(A)
Noise at normal temperature (acoustic pressure) [dB(A)]	55 dB(A)
Number of card slots	0
Number of power slots	1
Number of fans modules	2
Redundant power supply	Not supported
Long-term operating temperature [°C(°F)]	-5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.)
Restriction on the operating temperature variation rate [°C(°F)]	When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
	Devices cannot start when the temperature is lower than 0°C (32°F).
Storage temperature [°C(°F)]	–40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity [RH]	5% RH to 95% RH (non-condensing)
Long-term operating altitude [m(ft.)]	0–5000 m (0–16404 ft.)
Storage altitude [m(ft.)]	0-5000 m (0-16404 ft.)
Power supply mode	Pluggable power supply
Rated input voltage [V]	AC input: 100 V AC to 240 V AC, 50/60 Hz
Rated input voltage [V]	High-voltage DC input: 240 V DC
Input voltage range [V]	AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz
Input voltage range [V]	High-voltage DC input: 190 V DC to 290 V DC
Maximum input current [A]	The current specifications are related to the pluggable power module. For details, see Pluggable Power Modules.
Memory	2 GB
Flash memory	Physical space: 1 GB
Console port	RJ45
Eth Management port	Not supported
USB	Supported
RTC	Not supported
RPS input	Not supported
Power supply surge protection [kV]	Differential mode: ±6 kV; common mode: ±6 kV
Ingress protection level (dustproof/waterproof)	IP20
Types of fans	Built-in
Heat dissipation mode	Air cooling for heat dissipation, intelligent fan speed adjustment
Airflow direction	Air intake from left, front, and right and air exhaust from rear
PoE	Supported
Certification	EMC certification
	Safety certification
	Manufacturing certification

FAQ
