Wireless Access Point AirEngine 5573-23H Wi‑Fi 7 Indoor AP with 1×2.5GE ports
● Model No.: AirEngine 5573-23H
● Port details: 1 x 2.5G BIDI optical port (built-in) + 1 x GE electrical port (RJ45)
● Application scenarios: Indoor coverage scenarios for small and medium-sized enterprises, universities, hospitals, supermarkets, etc.
● Feature: Built-in 2.5G BIDI single-fiber optical port + GE electrical port
● Warranty: 1years
● MOQ: 1 pieces
Application scenarios
Office space for small and medium-sized enterprises (all-light industrial park)
Educational institutions (classrooms/libraries/dormitories)
Medical facilities (general wards/waiting areas)
Hotels/Apartments (all-light renovation)
Supermarkets/Retail/Chain stores
Key selling points
Supports core Wi-Fi 7 technologies such as 4096QAM, MLO (Multi-Link Aggregation), OFDMA, and 160MHz bandwidth. With speeds up to 2.88Gbps in the 5GHz band, it offers a high-speed, low-latency experience while costing less than the 5773 series, making it an economical choice for small to medium-sized applications adopting Wi-Fi 7.
Built-in 2.5G BIDI optical port: Supports bidirectional transmission over a single fiber, with a maximum coverage distance of 1 kilometer, significantly saving fiber optic resources.
Perfectly supports hybrid fiber-optic and all-optical Ethernet solutions, eliminating the need for separate cabling and reducing TCO, making it especially suitable for long-distance and difficult-to-lay scenarios.
Employs a built-in smart antenna supporting beamforming technology. It automatically adjusts the signal direction, accurately focusing as the terminal moves, reducing signal blind spots and interference, and ensuring uniform coverage and stable connection.
Built-in BLE 5.2 Bluetooth module, supporting local Bluetooth maintenance and asset location.
Detailed description
| parameter item | Specification Description |
| Product Model | AirEngine 5573-23H |
| Applicable scenarios | Indoor coverage scenarios for small and medium-sized enterprise offices, universities, hospitals, supermarkets, etc |
| wireless protocol | Wi-Fi 7 (802.11be)， Fully compatible with 802.11a/b/g/n/ac/ax |
| Antenna type | Built in dual frequency common interface smart antenna (with a 100% increase in signal strength at the same location) |
| RF and Space Flow | Dual RF design: 2.4GHz (2 × 2 MIMO)+5GHz (2 × 2 MIMO), with 4 spatial streams for the entire machine |
| Maximum speed of the whole machine | 3.57 Gbps（2.4GHz 689Mbps + 5GHz 2.88Gbps） |
| uplink interface | 1 x 2.5GE/GE optical port (LC, built-in BIDI optical module) |
| Downstream Interface | 1 x GE electrical port (RJ45, 10/100/1000M adaptive) |
| power supply method | PoE power supply for optoelectronic hybrid cable (802.3at/af), supporting 2km long-distance power supply |
| Maximum Power Consumption | 13.1 W (excluding USB) |
| Maximum number of users | ≤ 1024 |
| Physical dimensions (diameter x height) | Φ180 mm × 35 mm |
| weight | 0.52 kg |
| Operating Temperature | -10℃ ～ +50℃ |
| Expansion of the Internet of Things | Built in BLE 5.2 Bluetooth+USB interface, supports extended RFID, ZigBee, etc |
| working mode | Fit, Fat, Cloud Management |
| First supported version | V600R024C10 |
| MTBF | 143.6 |
