HiSecEngine USG6620F Security AI Firewall with 6×10GE ports

USG6620F security firewall 1u with 6×10GE SFP+ 8×GE COMBO 4×GE RJ45
The USG6620F is a 1U entry-level enterprise AI firewall in the USG6600F series. It is designed for scenarios involving small and medium-sized enterprise outbound connections, large enterprise branch offices, high-density gigabit access, and basic 10-gigabit uplinks. It is a highly cost-effective entry-level model in the series.

● Model No.: USG6620F

● Size: 442mm × 420mm × 43.6mm

● Interface configuration:  6×10GE SFP+ (10 Gigabit Optical),8×GE COMBO (RJ45/SFP Switchable),4×GE RJ45 (Gigabit Electrical)

● Main features: It features a 16-core high-performance CPU and 32GB of RAM, comes standard with dual power supply redundancy, and integrates an AI threat detection engine.

● Application scenarios: Internet gateways for medium-sized enterprises, core facilities of branch offices, or small and medium-sized data centers

● Warranty: 1 years

● MOQ: 1 pieces

5.0
design customization

    oops...!

    no product data.

    Go to homepage

    Application scenarios

    As an enterprise egress firewall, it blocks external attacks such as DDoS attacks and malware.


    It supports remote work and branch office interconnection through VPN functionality.


    Deployed at the campus network boundary, it enables deep inspection of egress traffic and control of internet behavior, protecting student network security.


    It safeguards patient data security, preventing data leakage or tampering.


    It supports compliance requirements for information security standards, avoiding the risk of business downtime.


    It establishes a secure tunnel through IPSec/SSL VPN, enabling encrypted data transmission between headquarters and branch offices.

    15 (5)
    H38b95d0f461841e5a5a9a3e39c91ec42z

    Core selling points

    6×10GE + 8×GE COMBO + 4×GE: Meets the needs of small to medium-sized networks with 10 Gigabit uplink and Gigabit hybrid access.


    1U Compact Design: Saves data center space and is compatible with standard racks and low-voltage boxes.


    No Expansion Slots: Low cost, simple deployment, fewer points of failure, suitable for budget-constrained scenarios.


    7G Threat Throughput: Stable performance when firewall, IPS, AV, and URL filtering are enabled simultaneously.


    AI Engine: 95%+ detection rate for unknown viruses and ransomware, defends against 0-day attacks and APTs.


    Application Identification (6000+): Precisely manages office, social, video, and database applications.


    Tens of thousands of CVE vulnerability coverage, comprehensive defense against web attacks (SQL injection, XSS, etc.).


    Dual power supply redundancy, hot-swappable fans, hardware bypass.

    Parameters

    parameter category Specification Details
    Product Model HiSecEngine USG6620F
    device form factor 1U rack mounted
    fixed port 6 × 10GE SFP+(10G optical)
      8 x GE COMBO (RJ45/SFP switchable)
      4 x GE RJ45 (Gigabit)
      1×Console, 1×MGMT, 1×USB3.0
    expansion slot No (fixed port design)
    Firewall throughput FW+SA:15 Gbps
      NGFW:14 Gbps
      Threat Protection (IPS+AV): 7 Gbps
    VPN performance IPsec VPN throughput: 15 Gbps
      Maximum IPsec tunnels: 10000
      SSL VPN throughput: 1.5 Gbps
      Maximum SSL users: 3000
    Concurrent connection 8 million
    make new connection 200000 CPS
    security policy 60000 pieces
    Virtualization (VSYS) 512 pieces
    power supply Dual AC power supply (1+1 redundancy), 100-240V AC
    heat dissipation 3+1 hot swappable intelligent fan
    Size (W × D × H) 442 × 420 × 43.6 mm
    weight About 6.0 kg
    Maximum Power Consumption 150W
    working environment Temperature: 0~45 ℃, humidity: 5%~95% (non condensing)
