Next-Generation Security Firewall USG6560F AI Enterprise Firewall with 8Gbps
● Model No.: USG6560F
● Size: 442mm × 420mm × 43.6mm
● Interface configuration: 16×GE RJ45 Ethernet ports + 8×GE Combo (electrical/optical multiplexing) + 2×10GE SFP+
● Main features: Flexible deployment and quiet operation
● Application scenarios: Small and medium-sized enterprises, chain stores, offices
● Warranty: 1 years
● MOQ: 1 pieces
Application scenarios
Cybersecurity Protection for SMEs
Network Management in the Education Sector
Data Protection in the Healthcare Sector
Branch Office Interconnection
Highly Sensitive Data Scenarios
Core selling points
Equipped with an AI-powered intelligent CDE detection engine, it deeply analyzes 100-layer compressed packets and encrypted traffic, achieving an unknown threat detection rate of >95%. Supporting 8Gbps throughput and 8 million concurrent connections for enterprise services, it supports 10 Gigabit bandwidth and high-density terminal access, ensuring security without performance loss.
Standard configuration includes 16xGE electrical + 8xGE Combo + 2x10GE SFP+ ports, boasting the highest port density among Huawei enterprise services across the entire network. It supports 10 Gigabit uplink and gigabit fiber-optic multiplexing, meeting the needs of high-scalability scenarios such as multi-dedicated line aggregation, server area access, and high-density terminals.
The new WebUI 2.0 visual interface supports policy self-learning, intelligent risk analysis, and minute-level fault location. It integrates with Huawei Qiankun Cloud for remote operation and maintenance, batch deployment, and real-time synchronization of cloud-based threat intelligence.
Parameters
| parameter category | Specification Details |
| Product Model | USG6560F |
| product form | 1U rack mounted |
| Firewall performance | The overall throughput of the machine is 8Gbps; Maximum concurrent connections of 8 million; New connection 200000/s |
| interface configuration | 16 x GE RJ45 electrical port+8 x GE Combo (electrical/optical)+2 x 10GE SFP+ |
| management interface | 1×RJ45 Console； 2×USB 2.0； 1 x MGMT management interface |
| safety function | NGFW、IPS、 Antivirus (CDE engine), URL filtering, APT defense Anti-DDoS、 Application control NAT、IPv6 |
| VPN capability | IPSec VPN (high-performance); SSL VPN 600Mbps； Maximum SSL user 500 |
| hardware configuration | 32GB DDR4 ECC； 4GB NAND Flash； Support M.2 SSD (64GB/240GB) hot swappable |
| Power supply and power consumption | Dual AC power supply (100~240V) with 1+1 redundancy; Maximum power consumption 280W |
| Size/Weight | 442mm × 420mm × 43.6mm（1U）； About 5.8kg |
| environmental adaptability | 0 ℃~45 ℃ (without hard drive)/5 ℃~40 ℃ (with hard drive); Humidity 5%~95% (no condensation) |
| management style | Web、CLI、SNMP、 Unified management of Huawei Qiankun Cloud and SecoManager |
| reliability | Dual power redundancy, 6kV lightning protection, VRRP dual machine hot standby, BFD fast switching, link aggregation |
