We provide customers with various communication products at reasonable prices and high quality products and services

Cloudengine S5735-S48T4XE-V2 98012044 48*10/100/1000base-t Ports 4*10ge Sfp+ Ports Network Switch 1

Cloudengine S5735-S48T4XE-V2 98012044 48*10/100/1000base-t Ports 4*10ge Sfp+ Ports Network Switch 2

Cloudengine S5735-S48T4XE-V2 98012044 48*10/100/1000base-t Ports 4*10ge Sfp+ Ports Network Switch 3

Cloudengine S5735-S48T4XE-V2 98012044 48*10/100/1000base-t Ports 4*10ge Sfp+ Ports Network Switch 4

Cloudengine S5735-S48T4XE-V2 98012044 4810/100/1000base-t Ports 410ge Sfp+ Ports Network Switch

Samples:

$505/piece | Min. order : 1 piece

Shipping:

Support Sea freight

Place of Origin:

China

Payments:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA

Lead Time:

1-10(pieces):3(days),11-50(pieces):7(days),51-100(pieces):15(days),>100(pieces):To be negotiated(days)

Customization:

Customized logo (Min. Order: 10000 sets),Customized packaging (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets)

Brand Name:

Model Number:

CloudEngine S5735-S48T4XE-V2

Inquiry

Write a Review

Use

other

Place of Origin

Guangdong, China

Type

Enterprise Switch

Product Description

S5700 series switches have enhanced Layer 3 features, simple operation and maintenance, flexible Ethernet networking, mature IPv6 features, and are widely used for enterprise campus access and aggregation, and data center access scenarios.

Reliability protection Powerful power supply capacity Network intelligent operation and maintenance

Item	Details
Description	S5735-S48T4XE-V2 (4810/100/1000BASE-T ports, 410GE SFP+ ports, 2*12GE stack ports, without power module)
Part Number	98012044
Model	S5735-S48T4XE-V2
First supported version	V600R022C01

Details Images

CloudEngine S5735-S48T4XE-V2 48*10/100/1000BASE-T ports 4*10GE SFP+ ports 98012044 Network Switch

Specification

Item	Specification
Dimensions without packaging (H x W x D) [mm(in.)]	Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.40 in. x 16.54 in.)
Dimensions without packaging (H x W x D) [mm(in.)]	Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 446.0 mm (1.72 in. x 17.40 in. x 17.56 in.)
Dimensions with packaging (H x W x D) [mm(in.)]	185 mm x 650 mm x 550 mm (7.28 in. x 25.59 in. x 21.65 in.)
Chassis height [U]	1 U
Weight without packaging [kg(lb)]	4.61 kg (10.16 lb)
Weight with packaging [kg(lb)]	7.74 kg (17.06 lb)
Typical power consumption [W]	50.93 W
Typical heat dissipation [BTU/hour]	173.78 BTU/hour
Maximum power consumption [W]	73.26 W (two 180 W AC power modules)
Maximum power consumption [W]	102.01 W (two 1200 W DC power modules)
Maximum heat dissipation [BTU/hour]	249.97 (two 180 W AC power modules)
Maximum heat dissipation [BTU/hour]	348.07 (two 1200 W DC power modules)
MTBF [year]	124.62 year
MTTR [hour]	2 hour
Availability	>0.99999
Noise at normal temperature (acoustic power) [dB(A)]	41.9 dB(A)
Noise at normal temperature (acoustic pressure) [dB(A)]	29.9 dB(A)
Number of card slots	0
Number of power slots	2
Number of fans modules	2
Redundant power supply	1+1
Redundant power supply	Power modules without fans and power modules with fans cannot be installed in the same chassis.
Long-term operating temperature [°C(°F)]	-5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.)

Why Choose Us

A)Stable and Wide Supply Chain System

we have established a perfect supply chain system to provide a wide range of products with reliable quality and reasonable price.

B)Competitive Price

We ensure the most competitive price. Warm reminders here, telecommunications equipment configuration is quite different, the price shown on the website is only for reference. After configuration and quantity been confirmed, we will give the final most competitive discounted price.

C) Safe and Easy Payment Solutions

We support a variety of payment methods, such as T/T, credit card, et

D)Fast Delivery and Shipping

Fast, professional and reliable delivery.

E)Complete and powerful pre-sales and after-sales service system

To provide customers with professional pre-sales service, as well as after-sales technical services

F)More Than 20 Years Industry Experience

we have been engaged in this industry more than 20 years, we have rich industry experience.

FAQ

Q: How about your main products?

A:Our product lines include Switches.Routers,OLTs,SDHs. Network Modules, Interface Cards, Security Firewalls, Wireless AP etc.

Q: What brand of products do you offer?

A:We are devoted to offering Huawei, ZTE, Cisco, Ruijie and other network equipment brands

Q:Can we get free samples?

A: Sorry, it is not available, but you can pay for one.

Q: What trade terms do you use ?

A: We offer EXW.FOB,CIF and CNF or as your request.

Q: How about your delivery time?

A:Generally, it will take 1 to 10 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.

Q: Do you test all your goods?

A:Yes we have professional engineer to test all devices before shipping.
